Hi,
First issue I see is that it concerns inline formatted text.
We clearly see the
\H10... as part of the export in your screen capture.
Curious, as there is no such blue text in the attached file.
For example:
- Main Point of Entry/New Switchbox
Behind Unit #2.
Is inline formatted to be 20 drawing units high with
\H20 while the Text entity Text Height property is 1000.
The formatting is probably not handled in SVG and the text is 1000 whatever large.
With line-art I presume that the pen size is converted to an SVG stroke width.
CAD Lineweights don't scale, it are the physical pen sizes from when we drew the design directly with ink ...
... SVG strokes scale with the overall displayed or printed size.
It will only look as several mm wide when the overall size is very large.
Displayed as scaled down to icon size it may even be not visible.
The stroke width of the line in this QCAD button
icon is for example 16 (in pixels).
What is quite large and it will hardly be more than a pixel wide when used in QCAD.
If you download it and display it in your browser, screen wide, the line is even much 'fatter'.
Perhaps the Advanced SVG export is a better option.
It is said to be able to "Preserve Geometry" but also that "The visual appearance of the output might not exactly match that of the CAD drawing".
Unsure if that strips inline formatting.
Regards,
CVH
